LTS Platinum Plus 128-Channel 8K Direct Search NVR, 16 SATA, 3U – LTN07128D-R16
LTS Platinum Plus 128-Channel 8K Direct Search NVR, 16 SATA, 3U – LTN07128D-R16 - Image 2
LTS Platinum Plus 128-Channel 8K Direct Search NVR, 16 SATA, 3U – LTN07128D-R16 - Image 3
LTS MPN LTN07128D-R16SKU LTN07128D-R16

LTS Platinum Plus 128-Channel 8K Direct Search NVR, 16 SATA, 3U – LTN07128D-R16

  • Video Input: 128 Ch IP @ 1280 Mbps (Independent output and 8K HDMI 3
  • Video Output: output resolution): HDMI 1/ VGA 1 / HDMI 2 / VGA 2, HDMI 3, and HDMI 4 provide independent output respectively. The
  • Max. Recording Resolution: maximum resolution is 8K + 4K + 1080p Up to 32 MP
  • Decoding Format: H.265+ / H.265 / H.264+ / H.264 / MPEG4 H.265+ / H.265 / H.264+ / H.264 / MPEG4
  • Decoding Capability: 4-ch @ 16 MP (30 fps) / 8-ch @ 8 MP (30 fps) 16-ch @ 4 MP (30 fps) / 32-ch @ 2 MP (30 fps)
$5,998.99 ● In stock · ships from the US
★ Earn 5,998 points ($59.98 back)U-Ecom RewardsYou get 1 point for every $1 when this order is completed. 100 points = $1 off a future order — redeem them for a coupon in your account. New accounts start with 100 points. How it works
Trade pricing apply to unlock
QuantityUnit price
1$5,998.99
2$5,939.00 −1%
3–4$5,879.01 −2%
5–19Trade account price
20+Request a quote
Request a project quote
  • ShippingFree in the US over $199
  • WarrantyManufacturer warranty
  • Returns30 days, no restocking fee
Not sure it fits your system? Call a tech: (+1) 720 744 3135

Overview

The LTS LTN07128D-R16 platinum Plus 128 Ch 8K Direct Search NVR, H.265+, 16 SATA up to 20TB each, 3U is part of the Platinum Plus line for professional security installs.

Resolution
32MP
Channels
128 IP channels
PoE ports
—
Storage
16 × SATA up to 20 TB each
Video output
output resolution): HDMI 1/ VGA 1 / HDMI…
Audio
1 in / 2 out

Key features

  • Human / Vehicle Detection
  • VCA 2.0
  • Direct-Search
  • Facial Recognition
  • RAID
  • Free US shipping over $199Flat $12.99 below that · details
  • 30-day returnsNo restocking fee · policy
  • Trade pricingInstallers & integrators · apply
  • Talk to a techCompatibility help · (+1) 720 744 3135

Specifications

Video Input 128 Ch IP @ 1280 Mbps (Independent output and 8K HDMI 3
Video Output output resolution): HDMI 1/ VGA 1 / HDMI 2 / VGA 2, HDMI 3, and HDMI 4 provide independent output respectively. The
Max. Recording Resolution maximum resolution is 8K + 4K + 1080p Up to 32 MP
Decoding Format H.265+ / H.265 / H.264+ / H.264 / MPEG4 H.265+ / H.265 / H.264+ / H.264 / MPEG4
Decoding Capability 4-ch @ 16 MP (30 fps) / 8-ch @ 8 MP (30 fps) 16-ch @ 4 MP (30 fps) / 32-ch @ 2 MP (30 fps)
Recorder AI Features Human / Vehicle Detection, VCA 2.0, Direct-Search, Facial Recognition, RAID
Audio In / Out IN: 1 line OUT: 2 lines RCA
Alarm Channels (In / Out) 32 / 16
Built-in PoE —
Network Interface 10 / 100 / 1000 / 2500 Mbps
Storage 16 × SATA up to 20 TB each
Hot Swap HDD Yes
Backup 2 × USB 2.0, 4 × USB 3.0
Dimensions (W × D × H) 17.4" × 19.5" × 5.7"

Downloads

Datasheet & manualsOn the LTS product page Spec sheet by emailWe reply with the PDF Firmware & setup helpCall (+1) 720 744 3135

Q&A

Can I buy this without a trade account?

Yes. Anyone can check out at the price shown. Installers and integrators can apply for a trade account for volume pricing and project quotes.

Will it work with my existing system?

Check the specifications above for supported protocols and power. If you are unsure, call (+1) 720 744 3135 with your current recorder or camera model and we will confirm before you order.

Do you offer pricing for larger projects?

Yes — send us a bill of materials through the quote form and we will reply with a single quote.
